Lens Material:

PC

Lens Diameter:

Ø10 mm

Edge Thickness:

4.5 mm

Design Wavelength:

780 nm

Clear Aperture (CA):

Ø4.3 mm

Numerical Aperture (NA):

0.11

Effective Focal Length (EFL):

19.97 mm

Back Focal Length (BFL):

18.2 mm

Axis Wave front Error (RMS):

0.028 λ

Transmittance (%):

90%

Storage Temperature:

-25 to 70°C

Operating Temperature:

5 to 65°C
